MOS-FET-Vollverstärker mit Class A/AB Hochstrom-Technologie
Der A 6.3 auf einen Blick
Erlesene OVATION Transistor-Technologie
- 2 x 200 W [8Ω] / 2 x 330 W [4Ω]
- Class A/AB high current MOS-FET technology adopted from the OVATION SA 6.3 Stereo Amplifier
- 20 MOS-FET transistors per channel deliver 180 Ampere max.
- Power amp supply with 1000 VA torodial transformer
- 4 separate power supplies: mains, processor unit, Silent power supply for für input circuit left & right
- Consistent dual-mono design eliminates avoids mutual interferences between channels
- Analog & true balanced input stages, fully DC-coupled
- 2 Variable pre-stage outputs (XLR & RCA/Cinch), 1 Fix Line Out (RCA/Cinch)
- Speakers A/B (separately switchable) with ultra stable loudspeaker terminals
- 5 High Level Inputs: 1 x XLR Balanced + 4 x RCA Unbalanced
- 5 Digital Inputs: 1 x RCA Coax, 2 x TOSLINK Opto, 1 x USB with up to 384kHz/32bit & DSD128 (via USB)
- Bluetooth 4.2
- Signal-sensitive inputs switches on A 8.3 / A 6.3 with incoming signal (1 x Analog RCA, 1 x Digital Coax, 1 x Digital Opto)
- Prepared for optional ARC Module
- Home Theater / AV Bypass
- 2 x Trigger Out (10V)
- Tone control incl. parametric loudness & bypass function
- Separate Class-A headphone amplifier with 6,3 mm jack
- Connector for external IR receiver
- Large, blue luminescent graphic display
- Comprehensive menu functions (adjustable input sensitivity, individual input naming and much more)
- Includes full aluminium RC 3 remote control
- 22 kg, Delivered in rugged AVM OVATION flight case
Der A 8.3 auf einen Blick
Exklusive OVATION 803 T Röhren-Technologie
- 2 x 200 W [8Ω] / 2 x 330 W [4Ω]
- Class A/AB high current MOS-FET technology adopted from the OVATION SA 6.3 Stereo Amplifier
- 20 MOS-FET transistors per channel deliver 180 Ampere max.
- Power amp supply with 1000 VA torodial transformer
- 4 separate power supplies: mains, processor unit, Silent power supply for für input circuit left & right
- Consistent dual-mono design eliminates avoids mutual interferences between channels
- Analog & true balanced input stages, fully DC-coupled
- 2 Variable pre-stage outputs (XLR & RCA/Cinch), 1 Fix Line Out (RCA/Cinch)
- Speakers A/B (separately switchable) with ultra stable loudspeaker terminals
- 5 High Level Inputs: 1 x XLR Balanced + 4 x RCA Unbalanced
- 5 Digital Inputs: 1 x RCA Coax, 2 x TOSLINK Opto, 1 x USB with up to 384kHz/32bit & DSD128 (via USB)
- Bluetooth 4.2
- Signal-sensitive inputs switches on A 8.3 / A 6.3 with incoming signal (1 x Analog RCA, 1 x Digital Coax, 1 x Digital Opto)
- Prepared for optional ARC Module
- Home Theater / AV Bypass
- 2 x Trigger Out (10V)
- Tone control incl. parametric loudness & bypass function
- Separate Class-A headphone amplifier with 6,3 mm jack
- Connector for external IR receiver
- Large, blue luminescent graphic display
- Comprehensive menu functions (adjustable input sensitivity, individual input naming and much more)
- Includes full aluminium RC 3 remote control
- 22 kg, Delivered in rugged AVM OVATION flight case
